Rám Cube AIM EX 29 CARAMEL 18"

FRAME Cube Aim EX

Completely revised, the brand-new Aim's sleek looks are thanks to its smooth-welded head tube and seat tube junctions. It incorporates a threaded bottom bracket and internal cable routing for long-lasting service and simple maintenance. There's even a flat disc mount that integrates seamlessly with the kickstand mount, and integrated mounting points for ACID mudguards and carrier. Updated geometry includes a lower top tube for more confident handling, and there's plenty of room to run wide, grippy and comfortable 2.25in tyres. The SizeSplit system has an expanded range too, so however tall you are there'll be an Aim that fits perfectly.

Product features - Cube Aim EX 29" Frame caramel´n´black

• Material: Aluminium Lite, AMF, Double Butted, Internal Cable Routing, Tapered Head Tube, Flat Mount Brake, SIC Mount, FM Kickstand Mount
• Seat post: 27.2mm
• Seat clamp: 31.8mm
• Front deraileur: 31.8mm / cable routing from below
• Headtube diameter: Tapered 1 1/8" - 1 1/2" (ZS44/28.6 - ZS56/40) semi-integrated
• Bottom bracket housing: BSA 73mm
• Disc brake mount rear: Flat-Mount
• Wheel size: 29"
• Recommended Fork Travel: 100mm
• Dropout: Standard quick release 135mm

Color

• caramel´n´black

Weight

• approx. 2100g (20")
